Direct Infusion™️ for the Marine Industry

As the infusion process has become more widespread the need to mechanise the handling, mixing and delivery of the resin has become more important. The traditional technique of hand-mixing bulk resin becomes impractical and potentially risky when using the process on any significant scale. Problems with material ratio consistency, potential bulk-exotherm and high levels of waste can have a significant detrimental effect on the viability of the process.

A meter-mixing machine can be used to simply dispense mixed resin ‘on demand’ into a suitable container but Composite Integration have taken the technology a step further by pioneering the development of systems capable of injecting ‘directly’ into the infusion process. The addition of strategically positioned in-mould pressure sensors (IMPS) to monitor infusion pressure, control flow rate and regulate volumetric compression, enables completely automated, precision control over the whole operation.

Typical Direct Infusion Strategy for Large Structures

Equipment Set-Up

The Ciject Four infusion machine has been developed specifically for large scale infusion processing, managing mix-ratio, infusion pressure and flow rates to provide unmatched levels of automation, efficiency and quality control.

Controlled Application

To achieve accurate mixing consistency and avoid potential bulk-exotherm while also minimising waste, our systems feature intelligent reactive monitoring with real-time response capabilities. Our IMPS technology feeds constant updates back to the Ciject machine to ensure unrivalled accuracy throughout the infusion process.

1) Ciject Four – Resin mixing and infusion
2) Manifold – Resin distribution
3) IMPS – Data feedback and control
4) Catchpot – Contaminant protection
5) Civac pump – Vacuum system
6) Consumables – Infusion film & PVC pipe

Marine Sector Guide

Please wait while flipbook is loading.

Product Package for large scale projects mixed resin projects over 1,200 kg with flow rates up to 18 kg per minute

"With Ciject systems now central to our manufacturing process, we’ve opened new possibilities for component design and have embraced a more creative approach with our latest product range"

Rob Coleman – Head of Manufacturing Engineering – Princess Yachts Ltd

"Composite Integration worked with us to help our team move away from conventional infusion to Direct Infusion using the Ciject equipment. Their level of support at every stage and the resulting efficiency improvements should be commended"

Adam Brangan – Director of Naval Architecture & Materials Engineering Sunseeker International Limited

Product Package for small to medium sized projects requiring mixed outputs of 0.1 to 10 kg a minute
